AUTHOR : kosafilter FROM : www.kosafilter.com ADD TIME : 2026-08-30 14:33 HITS : BELONG : COMPANY NEWS Non-Woven Bag Filter Clapboard: withoutClapboard FilterNumber: 1 MediumMaterial: SyntheticFiber Efficiency: F7 FiltrationGrade: MediumFilter Type: BagFilter Model NO. HBP Frame Plastic/Al Media Non
| Model | Dimensions | No. of Pockets | Media Area (m2) | Initial Pressure Drop (Pa) @ Air Flow (m3/h) | ||
| W×H×D (mm) | G3 | G4 | M6 | |||
| HBP-24×24×14-6P | 592×592×381 | 6 | 3.3 | 25@2500 40@3600 | 35@2500 60@3600 | 80@2500 |
| HBP-20×24×14-5P | 490×592×381 | 5 | 2.7 | 25@2100 40@3000 | 35@2100 60@3000 | 80@2000 |
| HBP-12×24×14-3P | 287×592×381 | 3 | 1.6 | 25@1250 40@1800 | 35@1250 60@1800 | 80@1250 |
| HBP-24×24×22-6P | 592×592×558 | 6 | 4.6 | 25@3800 40@5400 | 35@3800 60@5400 | 55@2500 85@3600 |
| HBP-20×24×22-5P | 490×592×558 | 5 | 4.1 | 25@3200 40@4500 | 35@3200 60@4500 | 55@2000 85@3000 |
| HBP-12×24×22-3P | 287×592×558 | 3 | 2.3 | 25@1900 40@2700 | 35@1900 60@2700 | 55@1250 85@1800 |
This product uses model no.: HBP.
This product uses frame: Plastic/Al.
Source: KOSA product catalog / internal documentation.
