AUTHOR : admin FROM : www.kosafilter.com ADD TIME : 2026-07-04 11:33 HITS : BELONG : COMPANY NEWS H13 H14 Commercial Laminar Flow HEPA Filter Ahu Filter Clapboard: withoutClapboard MediumMaterial: Fiberglass Efficiency: H13-U17 FiltrationGrade: HEPAFilter Type: PanelFilter FilterEfficiency: H13-U17(
| Model | Dimensions | Rated Air Flow | Rated Air Flow | Initial Pressure Drop |
| W×H×D (mm) | (m3/h) | (m3/h) | (Pa) | |
| HMF 305/10-50 | 305×305×50 | 1.6 | 200 | ≤102@H14 |
| HMF 610/05-50 | 305×610×50 | 3.3 | 400 | |
| HMF 610/10-50 | 610×610×50 | 6.7 | 820 | |
| HMF 570/20-50 | 1170×570×50 | 12 | 1440 | |
| HMF 1170/10-50 | 1170×1170×50 | 24 | 2950 |
KOSA makes various other models of HMH filter not listed the above table. Please consult with us if you need.
Filter efficiency can be 99.99% and above.
1.Adopt computer-controlled automatic production line for manufacturing, the crest height of folding filter material can be regulated steplessly between 18~96 mm, width will reach 1240mm at the widest.
2.Use PTFE as the filter material with long service life.
3.Double side retainers, protect the filter media, good strength.
4.Light in weight, compact in structure.
5.Each ULPA filter is tested according to EN1822:2009.
This product uses model no.: HMF.
This product uses frame: Anodized Aluminum Alloy.
Source: KOSA product catalog / internal documentation.
